Higher throughput
Process up to 32 PCR-tube samples in one rack instead of splitting the batch across smaller separators.
32 samples without disappearing into a plate.
When bead-based workflows grow beyond 8 or 16 samples, plate-format magnetic separation can start to look like the obvious next step. ClearUpp32 gives you another option: 32 individual PCR tubes arranged as two rows of sixteen.
The higher-throughput format keeps each sample individually accessible, and the tube-by-tube layout keeps the beads in view during aspiration and wash steps. You get more capacity without giving up the visual control of working in tubes.
Keep samples visible
Individual PCR tubes remain directly visible and accessible throughout the magnetic-separation workflow.
Plate alternative
A practical option for medium-throughput workflows where you want more capacity without moving the separation step into a plate.
Benchmarked against commercial alternatives.
ClearUpp32 has been benchmarked in our hands against commercial magnetic-separation racks under comparable conditions and showed similar separation performance.
That is also why we are comfortable offering a simple performance guarantee: if you are unhappy with how it performs as a magnetic separator, we will refund your purchase.
Specifications
| Intended use | Magnetic bead separation in PCR clean-up, NGS library preparation, CUT&RUN, CUT&Tag and other nucleic-acid or protein purification procedures |
| Capacity | 32 × 0.2 mL PCR tubes |
| Tube compatibility | Standard 0.2 mL PCR tubes and 8-tube PCR strips |
| Format | 2 × 16 positions |
| Working volume | 5–200 µL |
| Separation time | Typically 1–2 min with concentrated SPRISelect beads* |
| Material | PETG, high-grade neodymium magnets |
| Operating conditions | Room temperature; maximum product temperature 40 °C |
| Dimensions | Approx. 195 × 32 × 24 mm |
| Colours | Dark beige/white · Misty blue/white · White/white |
| Manufacture | Designed and manufactured by Assay Upp AB · Made in Sweden |
| Use | For professional laboratory use only · Research use only |
* Separation time may vary with bead concentration, sample volume and protocol conditions.
Care & handling
- Clean by wiping with a damp cloth.
- Avoid prolonged exposure to direct UV light.
- Avoid prolonged contact with organic solvents.
- Do not autoclave.
Magnet warning: Contains strong permanent magnets. Keep away from magnetically sensitive equipment and magnet-sensitive implanted medical devices.
Why 3D printing here?
This rack is manufactured in PETG using a controlled additive-manufacturing process. For a specialised tool produced in relatively small series, this lets us keep the geometry tied closely to the workflow and improve the design without waiting for a new mould.
